MyIAD GPS Tracker (MYT-10)


Feature List:

  • Real Time Tracking
  • AGPS & OTA
  • Intelligentized Working 3D G sensor
  • Low Power Consumption and Long Standby Time
  • Supports DC 10 ~100V wide supply voltage
  • Geo Fence
  • Vibration Alarm
  • Displacement Alarm
  • Low Power alarm
  • LNA (Low Noise Amplifier)
  • SNR (Signal-Noise Ratio)
  • G Sensor (Gravity Sensor)
  • CDN – Content Delivery Network
  • SMS – Short Message

MYT-10 is the smallest vehicle GPS tracker in the market now, its size just like two coins. As the small size , it is easily to be installed in the hidden area in your car. The wide working voltage 10-100V, can be used in any vehicles-cars, motorcycle, E-bike, bus and truck.

Items Value
GSM frequency 850MHz/900MHz/1800 MHz/1900 MHz
GPS chip Compatible with u-blox/BDS
GPRS Class 12,TCP/IP build in GSM MODULE
Sensitivity of GPS -163dBm
GPS Accuracy 10m (open sky)
Cell ID Accuracy 50-2000m
Speed Accuracy 0.1m/s
Warm Start-up 2s (open sky)
Cold Start-up ≤35s (open sky)
A-GPS Start-up ≤25s (open sky)
3D G-Sensor ±8g(All Direction)
Backup Battery 40mAh/ 3.7V
Storage Temperature -40~+85゜C
Operating Temperature -20~+70゜C
Humidity 20%~80%RH
Operating Voltage Range 10V~100V DC
Operating Current < 50mA
Sleeping Current < 3.5mA
Dimensions 72*32*15mm
Net Weight 42g
